Gigabyte B860M E GEN5 DDR5 Intel LGA1851 Micro ATX Motherboard

Gigabyte B860M E GEN5 Intel LGA1851 Micro-ATX Motherboard – DDR5, PCIe 5.0 Performance

Build a modern and efficient Intel system with the Gigabyte B860M E GEN5 Motherboard, designed for Intel Core Ultra (Series 2) processors. With PCIe 5.0 support, DDR5 memory and high-speed storage, this compact micro‑ATX board delivers reliable performance for everyday computing, productivity and entry-level gaming.

Key Features & Benefits

Next-Gen Intel Core Ultra Support (LGA1851)
Compatible with the latest Intel Core Ultra processors, providing powerful performance and future-ready platform support.

PCIe 5.0 Graphics Slot
Equipped with a PCIe 5.0 x16 slot, delivering maximum bandwidth for next-generation GPUs and ensuring long-term compatibility.

DDR5 High-Speed Memory Support
Supports up to 128GB DDR5 RAM with speeds up to 8800MT/s (OC), enabling faster multitasking and improved system responsiveness.

Dual M.2 PCIe 4.0 Storage
Includes 2 x M.2 slots, offering high-speed NVMe SSD support for quicker boot times and faster data transfer.

Efficient Power Delivery (4+1+2 VRM)
The hybrid VRM design ensures stable power output for consistent performance during everyday use and workloads.

Smart Fan & Cooling Control
Advanced cooling features with fan monitoring and control, helping maintain stable temperatures and quiet operation.

EZ-Latch PCIe Design
Quick-release PCIe slot for easy GPU installation and removal, simplifying system assembly and upgrades.

Modern Display Connectivity
Includes HDMI and DisplayPort outputs, supporting high-resolution displays for productivity and entertainment.

Technical Specifications

CPU Support

• Intel LGA1851 Socket
• Supports Intel Core Ultra Processors (Series 2)

Chipset

• Intel B860

Memory

• 2 x DDR5 DIMM Slots
• Up to 128GB Capacity
• Dual Channel Architecture
• Speeds up to 8800MHz (OC)
• XMP Support

Storage

• 2 x M.2 PCIe 4.0 Slots
• 4 x SATA 6Gb/s Ports
• RAID 0 / 1 / 5 / 10 Support

Graphics Outputs

• 1 x HDMI 2.1 (up to 4K@60Hz)
• 1 x DisplayPort 2.1 (up to 4K@144Hz)

Expansion Slots

• 1 x PCIe 5.0 x16
• 1 x PCIe 3.0 x1

Networking

• Realtek Gigabit LAN (10/100/1000 Mbps)

Audio

• Realtek HD Audio
• 2/4/5.1/7.1-channel support
• S/PDIF support

USB Connectivity

• USB 3.2 Gen1 ports (rear & internal)
• USB 2.0 ports

Internal Connectivity

• 2 x ARGB headers (Gen2)
• Fan & pump headers
• TPM header
• SATA connectors

Rear I/O Ports

• HDMI & DisplayPort
• 4 x USB 3.2 Gen1
• 2 x USB 2.0
• RJ-45 LAN
• Audio jacks
• PS/2 port

Form Factor

• Micro-ATX (24.4cm x 21.5cm)

Operating System Support

• Windows 11 (64-bit)
• Windows 10 (64-bit)

Why Choose the Gigabyte B860M E GEN5?

The Gigabyte B860M E GEN5 is a compact and capable motherboard designed for modern Intel systems. With PCIe 5.0 graphics support, DDR5 memory and dual M.2 storage, it offers a reliable balance of performance and value.

Ideal for home users, office builds and entry-level gaming PCs, it provides essential features, stable performance and future-ready compatibility, making it a solid foundation for your next build.
