Ubiquiti U7-LR UniFi 7 Long Range WiFi 7 Access Point, 2.5GbE PoE
Ubiquiti U7-LR UniFi 7 Long Range WiFi 7 Access Point, 2.5GbE PoE
Unlock unparalleled wireless performance and coverage with the Ubiquiti U7-LR UniFi 7 Long Range Access Point. Designed for demanding environments, this cutting-edge WiFi 7 AP delivers ultra-fast speeds and reliable connectivity across large areas — perfect for offices, campuses, hotels, and smart buildings.
Key Features & Benefits
-
Next-Gen WiFi 7 Technology
Supports 5 spatial streams across 5 GHz and 2.4 GHz bands, delivering blazing speeds up to 4.3 Gbps on 5 GHz and 688 Mbps on 2.4 GHz for seamless streaming, gaming, and productivity. -
Extended Wireless Coverage
Covers up to 160 m² (1,750 ft²) to provide strong, stable WiFi throughout your space, eliminating dead zones. -
High Client Capacity
Efficiently handles 300+ simultaneous connected devices, ideal for busy networks with multiple users. -
2.5 GbE High-Speed Uplink
Features a 2.5 GbE RJ45 port for fast and reliable backhaul to your core network. -
Flexible Installation
Includes ceiling and wall mounting options with a plastic mounting plate for versatile deployment. -
Advanced MU-MIMO & Radio Management
Supports 3x3 MU-MIMO on 5 GHz and 2x2 MU-MIMO on 2.4 GHz, with intelligent band steering and radio resource management for optimised network efficiency. -
Secure Guest Access
Built-in captive hotspot portal with voucher/payment authentication, guest isolation, and dynamic VLAN support for controlled and safe guest networking. -
Power over Ethernet (PoE)
Simplifies installation by powering the device through a single Ethernet cable — no additional power supply required.
Technical Specifications
| Feature | Specification |
|---|---|
| Dimensions | Ø175.7 x 43 mm (6.9 x 1.7 in) |
| WiFi Standard | WiFi 7 (802.11be), backward compatible with WiFi 6/5/n |
| Spatial Streams | 5 (3x3 on 5 GHz, 2x2 on 2.4 GHz) |
| Max Data Rate | 5 GHz: 4.3 Gbps, 2.4 GHz: 688 Mbps |
| Coverage Area | Up to 160 m² (1,750 ft²) |
| Max Clients | 300+ |
| Uplink Port | 1 x 2.5 GbE RJ45 |
| Power | PoE (42.5–57 V DC) |
| Antenna Gain | 5 GHz: 6 dBi, 2.4 GHz: 4 dBi |
| Max TX Power | 5 GHz: 27 dBm, 2.4 GHz: 26 dBm |
| Operating Temperature | -30 to 50° C (-22 to 122° F) |
| Weight | 448 g (15.8 oz) |
| Enclosure Material | Polycarbonate, aluminium alloy |
| Mount Material | Polycarbonate, galvanised steel (SGCC) |
| Certifications | CE, FCC, IC |
| Management | Ethernet via UniFi Controller |
| NDAA Compliant | Yes |
Advanced Features
-
Wireless Meshing for flexible network expansion
-
Band Steering, Fast Roaming (802.11r), Radio Resource Management (802.11k)
-
Captive Hotspot Portal with custom branding, voucher, and payment-based authentication
-
Client isolation, WiFi speed limiting, and scheduling controls
-
Secure RADIUS over TLS (RadSec) and dynamic RADIUS VLAN assignment
Why Choose the U7-LR?
The Ubiquiti U7-LR UniFi 7 Access Point sets a new standard in wireless networking by combining next-generation WiFi 7 speed, extended range, and high device capacity in a sleek, easy-to-install design. Whether for busy offices, educational campuses, or hospitality venues, it ensures fast, reliable, and secure connectivity to meet today’s demanding wireless needs.
