TP-Link ER706W Omada AX3000 Gigabit VPN Router — Powerful Mesh WiFi & VPN for Secure Networks
The TP-Link ER706W Omada AX3000 VPN Router is a high-performance, dual-band router designed to provide fast, reliable, and secure wired and wireless connections. Whether for office, hospitality, or large-scale deployments, the ER706W integrates powerful VPN options, robust security, and centralised Omada management — all in one compact device.
Key Features & Benefits
✅ Blazing AX3000 Dual-Band WiFi
Enjoy speeds up to 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz for smooth streaming, gaming, and business operations.
✅ Flexible Gigabit Connectivity
Equipped with 1 Gigabit SFP, 1 Gigabit WAN, and 4 Gigabit LAN/WAN ports for high-speed wired networking.
✅ Omada Mesh & Seamless Roaming
Seamlessly integrates with Omada EAPs supporting mesh technology — perfect for scalable and unified WiFi coverage.
✅ Advanced VPN & Security
Supports IPSec, SSL, WireGuard, PPTP, L2TP, and OpenVPN with high throughput. Protects with firewall, DoS defence, IP/MAC/URL filtering, and more.
✅ Cloud-Based Central Management
Easy control with Omada Cloud, hardware or software controllers, and mobile app for streamlined network administration.
✅ Detachable High-Gain Antennas
Triple external antennas ensure boosted WiFi coverage and stable connections.
⚙️ Technical Specifications
| Feature | Specification |
|---|---|
| WiFi Speeds | 5 GHz: 2402 Mbps / 2.4 GHz: 574 Mbps |
| Interfaces | 1x Gigabit SFP, 1x Gigabit WAN, 4x Gigabit LAN/WAN, 1x USB 3.0 |
| VPN Protocols | IPSec (100 tunnels), SSL (50 tunnels), WireGuard, PPTP, L2TP, OpenVPN |
| Concurrent Sessions | 150,000 |
| Management | Omada Cloud, App, OC300/OC200 controllers |
| Antenna | 2 x 3 dBi (2.4 GHz), 3 x 4.5 dBi (5 GHz), detachable |
| Dimensions | 226 x 131 x 35 mm (8.9 x 5.2 x 1.4 in) |
| Power Supply | 12V DC / 2A adapter (included) |
| Max Power Use | 16.8W (EU) / 22.7W (US) with USB connected |
| Certifications | CE, FCC, RoHS |
⚡ Why Choose the ER706W?
The TP-Link ER706W Omada AX3000 VPN Router combines advanced performance, enterprise-grade security, and seamless integration with Omada’s ecosystem. It’s the ideal choice for businesses that need scalable, secure, and easy-to-manage networking.
