LINDY 38249 4-Port HDMI 2.0 18G Switch with Audio & HDR Support

LINDY 38249 4-Port HDMI 2.0 18G Switch with Audio

Seamlessly Switch Between 4 HDMI Sources with 4K 60Hz & HDR Support

The LINDY 38249 4-Port HDMI 2.0 Switch is a high-performance HDMI switcher that allows you to seamlessly switch between four HDMI source devices and output to a single HDMI display. With support for 4K UHD at 60Hz, HDR, and 18Gbps bandwidth, this switch ensures crystal-clear visuals and immersive audio for home theaters, gaming setups, and professional AV environments.

Built with integrated audio extraction, the LINDY 38249 allows you to output digital and analogue audio separately via 3.5mm stereo and optical (Toslink) connections. This makes it perfect for use with sound systems, AV receivers, and home entertainment setups.

Key Features & Benefits:

✅ 4 HDMI Inputs, 1 HDMI Output – Seamlessly switch between four HDMI 2.0 source devices to a single HDMI display.

✅ 4K 60Hz UHD with HDR – Supports resolutions up to 3840 x 2160 @ 60Hz 4:4:4 8-bit, delivering sharp, vibrant visuals.

✅ 18Gbps Bandwidth & HDCP 2.2 Support – Ensures high-speed data transfer for smooth playback of HDR content, gaming, and UHD streaming.

✅ Digital & Analogue Audio Extraction – Separate audio from HDMI sources with 3.5mm stereo and Toslink (optical) outputs for enhanced sound compatibility.

✅ Multiple Control Options – Control via IR remote, push button, auto-switching, and RS232 for professional setups.

✅ Auto-Switching for Active Sources – Automatically detects and switches to the active HDMI source, reducing manual input selection.

✅ CEC Pass-Through – Supports Consumer Electronics Control (CEC) for seamless interaction with connected devices.

✅ Compact & Durable Design – Slim metal housing for durability and heat dissipation, ideal for home and professional AV environments.

✅ Plug-and-Play Setup – Simple installation with included accessories like an IR remote, RS232 cable, power supply, and optical adapter.

Technical Specifications:

• AV Interface: HDMI 2.0

• Maximum Resolution: 4K @ 60Hz (3840 x 2160) 4:4:4 8-bit

• HDR Support: Yes

• HDCP Support: HDCP 2.2

• Bandwidth: 18Gbps

• Audio Support:

  • Analogue 2CH via 3.5mm jack

  • Up to 5.1CH via Optical (Toslink)

  • Audio pass-through via HDMI

• Separate Audio Outputs: 3.5mm stereo, Optical (Toslink)

• Control Methods:

  • IR Remote (38kHz)

  • Push Button

  • RS232 (3.5mm)

  • Auto-Switching

• Inputs: 4 x HDMI Type A (Female)

• Outputs:

  • 1 x HDMI Type A (Female)

  • 1 x 3.5mm Stereo (Analogue)

  • 1 x Toslink Optical (Digital)

• Power Supply: 5V DC, 1A

• Dimensions: 180 x 85 x 11.6 mm

• Weight: 0.563 kg (1.24 lb)

• Operating Temperature: 0°C - 40°C (32°F - 104°F)

• Storage Temperature: -20°C - 60°C (-4°F - 140°F)

• Humidity: 20-90% RH (non-condensing)

What's in the Box?

✔ LINDY 38249 HDMI Switch
✔ Multi-Country Power Adapter (UK, EU, US, AUS)
✔ IR Extension Cable (1.5m)
✔ Mini Optical to Optical Adapter
✔ Remote Control & CR2032L Battery
✔ 3.5mm RS232 Cable (1m)
✔ User Manual

Ideal For:

✅ Home Theaters & Entertainment Systems – Easily switch between gaming consoles, Blu-ray players, media streamers, and set-top boxes.
✅ Professional AV & Conference Rooms – Perfect for presentations, digital signage, and multi-source video setups.
✅ Gaming Setups – Reduce HDMI input switching hassle and enjoy 4K 60Hz gaming with HDR support.
✅ High-End Audio Systems – Extract high-quality digital and analogue audio for use with AV receivers and sound systems.

Upgrade Your AV Setup with the LINDY 38249 HDMI Switch

The LINDY 38249 4-Port HDMI 2.0 Switch with Audio Extraction is a must-have for anyone looking to streamline their AV setup while ensuring high-quality 4K 60Hz visuals and immersive audio. Whether you’re setting up a home cinema, gaming station, or professional AV environment, this HDMI switch delivers seamless connectivity, intuitive control, and premium performance.

Order yours today and experience effortless HDMI switching!
