Mercusys MS105GP 5-Port Gigabit PoE+ Switch – Desktop/Wall Mount
Mercusys MS105GP 5-Port Gigabit Desktop Switch with 4-Port PoE+
The Mercusys MS105GP is a compact, high-performance 5-Port Gigabit switch designed for small businesses, offices, and smart homes. With 4 PoE+ ports, durable metal construction, and energy-saving features, it delivers reliable connectivity for IP cameras, access points, and VoIP phones.
Key Features & Benefits
✅ Full Gigabit Performance – 5 × 10/100/1000 Mbps RJ45 ports with auto-negotiation and Auto-MDI/MDIX for fast, reliable connections.
✅ 4-Port PoE+ Support – Power IP cameras, access points, or VoIP phones directly through the network cable, reducing the need for extra adapters.
✅ Durable Metal Casing – Sturdy steel housing ensures efficient heat dissipation and long-term stability.
✅ Flexible Installation – Desktop or wall-mountable design to suit your workspace.
✅ Plug & Play – No configuration required, making setup fast and hassle-free.
✅ Energy-Efficient – Green Ethernet technology reduces power consumption automatically.
Technical Specifications
Hardware
-
Interfaces: 5 × 10/100/1000 Mbps Auto-Negotiation RJ45 ports (Auto MDI/MDIX)
-
Power Supply: 5V/0.6A external adapter
-
Casing: Metal, desktop or wall-mountable
-
Dimensions: 3.92 × 3.86 × 0.99 in
Performance
-
Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3x CSMA/CD
-
Data Rates: 10/100/1000 Mbps (half duplex), 20/200/2000 Mbps (full duplex)
-
Transfer Method: Store-and-forward
-
Buffer Capacity: 1 Mbit
-
Jumbo Frame: 15 KB
-
LEDs: Power, Ethernet ports (1–5)
Package Contents
-
Mercusys MS105GP 5-Port Gigabit Desktop Switch
-
Power Adapter
-
Quick Installation Guide
Why Choose the Mercusys MS105GP?
Whether you’re expanding a home network, setting up IP surveillance, or powering multiple PoE+ devices, the Mercusys MS105GP provides a cost-effective, high-speed, and energy-efficient solution. With its robust metal build, plug-and-play convenience, and PoE+ functionality, it ensures stable and efficient networking with minimal setup.
