Ubiquiti U7-Pro-XG WiFi 7 Ceiling Access Point, 10GbE, 6GHz

Ubiquiti UniFi U7-Pro-XG – Ultra-Fast WiFi 7 Access Point with 6GHz & 10GbE

The Ubiquiti UniFi U7-Pro-XG is a high-performance WiFi 7 access point engineered for demanding indoor environments. With 6 spatial streams, full support for the 6GHz band, and a blazing-fast 10GbE uplink, it delivers unmatched wireless speed and capacity—perfect for enterprise, hospitality, and high-density user deployments.

Offering coverage up to 140 m² (1,500 ft²) and support for 300+ concurrent clients, the U7-Pro-XG maximizes spectrum efficiency through features like OFDMA, MU-MIMO, band steering, and advanced radio management. Its sleek, ceiling-mountable design integrates seamlessly into modern spaces.

Key Features

✔ WiFi 7 (802.11be) – Next-generation wireless with 6GHz support
✔ 6 Spatial Streams – High-capacity throughput across 2.4GHz, 5GHz & 6GHz
✔ 10GbE Uplink – Lightning-fast backhaul via PoE+
✔ Ceiling/Wall Mountable – Lite mounting kit included
✔ 300+ Concurrent Clients – Enterprise-ready user density
✔ Coverage up to 140 m² – Ideal for large rooms, offices, or public spaces
✔ Advanced Wireless Features – Band steering, fast roaming, WiFi scheduling
✔ Modern Security – PPSK, WPA3, RADIUS over TLS (RadSec)
✔ Wireless Meshing & Hotspot Support – Expand coverage and manage guests

Technical Specifications

Physical & Power

• Dimensions: 206 x 32.5 mm

• Weight: 750g

• Enclosure Material: UV-stabilized polycarbonate, aluminium alloy

• Mounting Options: Ceiling or wall (Lite mount included)

• Power Method: PoE+ (42.5–57V DC), 22W max

• LEDs: System

Networking

• Interface: 1 × 10GbE RJ45 port

• Management Interface: Ethernet

• Wireless Meshing: Supported

WiFi Capabilities

• Standards: 802.11a/b/g/n/ac/ax/be

• MIMO Configuration:

  • 2.4GHz: 2×2 MU-MIMO – 688 Mbps

  • 5GHz: 2×2 MU-MIMO – 4.3 Gbps

  • 6GHz: 2×2 MU-MIMO – 5.8 Gbps

• Antenna Gain:

  • 2.4GHz: 4 dBi

  • 5GHz: 5 dBi

  • 6GHz: 6 dBi

• Max TX Power:

  • 2.4GHz – 23 dBm

  • 5GHz – 26 dBm

  • 6GHz – 24 dBm

Software Features

• Concurrent BSSIDs: 8 per radio

• Band Steering, 802.11k/r/v – Yes

• Advanced Radio Management & RRM – Yes

• Passpoint (Hotspot 2.0) & Captive Portal – Yes

• Private Pre-Shared Key (PPSK) – Yes

• WiFi Speed Limiting, Client Isolation, Schedules – Yes

• Security: WPA2/WPA3, RADIUS over TLS (RadSec)

• Channel Bandwidths:

  • HT: 20/40 MHz

  • VHT: 20/40/80/160 MHz

  • HE: 20/40/80/160 MHz

  • EHT: 20/40/80/160/240/320 MHz

Certifications

• CE, FCC, IC

Ideal For:

• Enterprise-grade wireless networks

• Large offices, conference centres, classrooms

• Indoor environments demanding 10GbE backhaul & next-gen WiFi

The Ubiquiti U7-Pro-XG redefines indoor wireless performance. With tri-band WiFi 7, 6GHz support, and 10GbE uplink, it delivers exceptional speed, capacity, and future-proof connectivity for next-generation networks.
