TP-Link Omada Fusion 2.5G PoE Gateway 9-Port Multi-WAN Router
All-in-One Omada Networking Hub for Modern Businesses
The TP-Link Omada Fusion 2.5G PoE Gateway combines an enterprise-grade security gateway, PoE switch and Omada controller into a single powerful device. Designed for small and medium-sized businesses, multi-site deployments and professional network environments, it delivers simplified management, multi-WAN connectivity, advanced security and high-speed 2.5GbE networking.
Featuring a quad-core processor, nine 2.5GbE ports, integrated PoE+ support, built-in Omada management and advanced VPN capabilities, the Omada Fusion Gateway provides the foundation for a secure, scalable and centrally managed network.
Key Features & Benefits
All-in-One Gateway, Switch & Controller
The Omada Fusion Gateway integrates:
- Enterprise Security Gateway
- Omada Hardware Controller
- 2.5GbE Network Switch
- PoE+ Power Delivery
This reduces hardware requirements and simplifies deployment, management and maintenance.
High-Speed 2.5 Gigabit Connectivity
Equipped with nine 2.5GbE Ethernet ports:
- 1 × 2.5G Dedicated WAN Port
- 8 × 2.5G LAN/WAN Ports
Ideal for high-performance internet connections, NAS devices, servers, Wi-Fi 6/6E/7 access points and modern business networks.
8-Port PoE+ Power Delivery
Power compatible network devices directly from the gateway with:
- 8 × PoE+ Ports
- 110W Total PoE Budget
Perfect for:
- Wireless Access Points
- IP Cameras
- VoIP Phones
- Networked Devices
Advanced Multi-WAN Load Balancing
Support up to eight simultaneous WAN connections with:
- Intelligent Load Balancing
- Automatic WAN Failover
- Improved Uptime
- Bandwidth Aggregation
Ensuring maximum reliability for mission-critical network connections.
Integrated Omada Controller
Manage your entire Omada ecosystem from a single platform with:
- Cloud Management
- Local Management
- Omada App Support
- Multi-Site Management
- Centralised Monitoring
Recommended for:
- Up to 30 Omada Devices
- Up to 300 Connected Clients
Touchscreen Network Management
An integrated 3.69-inch colour touchscreen allows:
- Local Network Monitoring
- Quick Troubleshooting
- Status Checks
- Reduced On-Site Visits
Providing direct access to key network information.
Bluetooth Guided Deployment
Quickly onboard devices using:
- Bluetooth Setup
- Omada App Configuration
- One-Tap Device Adoption
- Automatic Device Discovery
Reducing installation time and deployment complexity.
Enterprise Security Features
Intrusion Detection & Prevention
The integrated IDS/IPS engine provides:
- Network Threat Detection
- Attack Prevention
- Deep Packet Inspection (DPI)
- Real-Time Protection
Advanced Security Services
Built-in security capabilities include:
- Stateful Firewall
- Application-Based ACLs
- Content Filtering
- DNS Security
- Ad Blocking
- Safe Search
- ARP Inspection
- Attack Defence
High Security Throughput
- IDS/IPS Throughput: 2,183 Mbps
Designed to protect networks without significantly impacting performance.
Advanced VPN & SD-WAN Capabilities
Omada LightLink VPN
Securely access your network remotely through one-click VPN connectivity.
Features include:
- Smart Split Tunnelling
- Reduced VPN Overhead
- Improved User Experience
- Secure Remote Access
Supported VPN Technologies
VPN Server Support
- WireGuard VPN
- OpenVPN
- IPsec VPN
- SSL VPN
- L2TP VPN
- PPTP VPN
VPN Client Support
- WireGuard VPN
- OpenVPN
- L2TP VPN
- PPTP VPN
Site-to-Site VPN
- IPsec VPN
- WireGuard VPN
VPN Performance
- IPsec VPN: 1,023 Mbps
- WireGuard VPN: 605 Mbps
- Omada LightLink VPN: 527 Mbps
- SSL VPN: 250 Mbps
- OpenVPN: 223 Mbps
- L2TP VPN: 892 Mbps
- PPTP VPN: 193 Mbps
Full Mesh SD-WAN
Create resilient, scalable multi-site networks with:
- Full Mesh Connectivity
- Centralised Management
- Automatic Path Selection
- WAN Optimisation
Technical Specifications
Hardware
- Quad-Core Processor
- 2GB DDR4 Memory
- Built-In Omada Controller
- Integrated Cooling Fan
- Reset Button
Display
- 3.69-Inch Colour LCM Touchscreen
Networking Ports
- 1 × 2.5G RJ45 WAN
- 8 × 2.5G RJ45 LAN/WAN
- 8 × PoE+ Ports
- Up to 8 Simultaneous WAN Connections
PoE
- PoE Standard: PoE+
- Total PoE Budget: 110W
Management
- Omada Cloud Management
- Local Web Management
- Omada Mobile App
- Multi-Site Management
- Automatic Device Discovery
- Network Topology Mapping
- Health Monitoring
- Event & Alert Logging
Diagnostics Tools
- Ping Test
- Packet Capture
- Terminal Access
- Cable Testing
- Interference Detection
- Port Mirroring
- Remote Access
- IntelliRecover
Physical Specifications
- Dimensions: 226 × 135 × 31.5mm
- Weight: 728g
Mounting Options
- Desktop Placement
- Wall Mount Compatible*
- Rack Mount Compatible*
*Mounting accessories sold separately.
Additional Networking Features
Routing & Network Services
- VLAN Segmentation
- DHCP Server
- Static Routing
- Policy Routing
- Multi-WAN Load Balancing
- QoS Management
- Bandwidth Control
- Dynamic DNS
- IPv6 Support
- Bonjour / mDNS
- IGMP Proxy
Authentication & Access Control
- Captive Portal
- RADIUS Authentication
- LDAP Authentication
- 802.1X Authentication
- OUI-Based VLAN Assignment
Why Choose the TP-Link Omada Fusion 2.5G PoE Gateway?
The TP-Link Omada Fusion 2.5G PoE Gateway is designed to simplify professional network deployment by combining multiple essential infrastructure components into a single powerful appliance. By integrating routing, switching, PoE power delivery and Omada management, it reduces complexity while delivering enterprise-class performance and security.
With support for 2.5GbE networking, advanced VPN technologies, SD-WAN functionality, touchscreen management and comprehensive security services, it provides everything needed to build and manage secure, high-performance business networks from one central platform.
Whether you're supporting a growing business, managing multiple sites or deploying advanced Omada environments, the Omada Fusion Gateway delivers exceptional scalability, flexibility and value.
Perfect For
- Small & Medium Businesses
- Multi-Site Organisations
- Managed Service Providers
- Retail Networks
- Hospitality Venues
- Schools & Educational Facilities
- Offices & Commercial Buildings
- Wi-Fi 6 / Wi-Fi 7 Deployments
- IP Camera Installations
- VoIP Phone Systems
- SD-WAN Networks
- Omada Ecosystem Deployments
